Specifications:
| Power supply | 2 pcs LI-batteries 3V exchangeable (CR2032) No need to switch on-off. |
| Viewing area | Viewing angle downwards: +37° Viewing angle sidewards: +25° |
| Sensors | Wide angle detection sensor |
| Light transmittance | Ultraviolet/infrared protection (maximum at any shade setting) Visible range activated shade level DIN 9-12 Visible range not activated shade level DIN 3 |
| Switching time | Light to dark at room temperature: 0.16 ms Light to dark at 55°C / 131°F: 0.110 ms |
| Dark to light | 0.3s |
| Classification EN 379 | 1/1/2/2 |
| Classification EN 175 | F (45m/s impact resistance) |
| Shape Stability | Welding mask up to 180°C / 356°F Front cover lens up to 135°C / 275°F |
| Grinding Mode | Shade level DIN 3 |
| Material | Rigid plastic face shield and flame retardent textile according to EN ISO 11611 (Class 1, A1+ A2) |
| Operation Temperature | -10°C to +60°C / 14°F to 158°F |
| Storage Temperature | -20°C to +80°C / -4°F to 176°F |
| Weight Helmet cpl. | approx. 400g |
Applications:
- Gas Welding
- TIG Welding (GTAW)
- Micro Plasma Arc Welding
- MIG/MAG (GMAW)
- Elektrode Welding (Stick Welding, SMAW)
- Spot welding
